All-Terrain Adaptation
Wheeled quadruped robotic chassis + Dual-track climbing system flexibly to various complex terrains. 14 sets of powered-systems provide exceptional stability and obstacle-crossing capabilities, making it effortless to navigate stair steep slopes, and rugged surfaces as if it traversing flat ground.
Multiple Operation Modes
Caterpiller Mode
Climbing and Obstacle-Surmounting Mode
Equipped with independent power systems for each wheel and quadruped joint, along with a four-wheel independent suspension system, this mode delivers exceptional cross-country performance and comfort. It adapts perfectly to diverse terrains including indoor/outdoor flat surfaces, rugged paths, grassy areas, and gravel roads.
Wheeled Quadruped Mode
The wheeled quadruped robot chassis is equipped with an independent power system and suspension shock absorption system for the four wheels, which has strong off-road performance and provides comfortable experience.
Combing caterpillar and wheeled quadruped mechanisms, this mode can address mobility challenges on stairs, steps, steep slopes and so on.
The robot uses LiDAR and gyroscopes to detect obstacles and map spatial environments. Advanced algorithms control robot deformation and movement, enabling fully autonomous navigation up and down stairs, across slopes, and over various terrain features while ensuring optimal intelligence, comfort, and safety.
Intelligently switches operational modes based on obstacle detection and user preferences to optimize terrain adaptation and maximize mobility performance.
Dynamically optimizes power distribution across all drive systems, including four-wheel drive, track mechanisms, and quadruped joints for maximum efficiency.
Continuously monitors and corrects unsafe postures or operations during operation to maintain user comfort and safety at all times.
know the X12 better
Specifications
Weight
About 50kg
Maximum Load
270kg
Balance Type
360° Full-time Automatic Balancing (Inclination Range: Forward & Backward 15°, Left & Right 8°, Other Directions 8~15°)
Maximum Driving Speed
12km/h
Range
35km
Chassis Type
Wheeled Quadruped Caterpillar Chassis
Movement Mode
1. Caterpillar Mode
2. Climbing&Obstacle-surmounting Mode:
3. Wheeled Quadruped Mode
Chassis Powertrain Quantity
10
Total Powertrain Quantity
14-16
Pitch Range
Tilt Forward: 8° Reclining: 43°
Battery Capacity
24V 44.8Ah
Sensor Type
LiDAR and Gyroscope
Assisted Safe Driving Warn
Standard Configuration
Downstairs Speed
35 Steps/min
30 Steps/min
Upstairs Speed
Reverse-Parking Radar
Standard Configuration
Seat Width
440~560mm
Seat Depth
370~500mm
Armrest Height
175-250mm
Backrest Width
400/450/500mm
Backrest Height
460~600mm
Front Wheel
10 Inch Mecanum Wheel
IPX5
Waterproof Rating
Stairs/Landing Dimensions and Angle Specifications
Maximum Stairs Width: 800mm
L-shaped Stair Corner 1060x1060mm
U-shaped Stair Corner 1060(Depth) *2000(Width)mm
Helical Angle<25°
Entertainment Feature
Gentle Sway Mode. AI-powered Mode
Locking/Unlocking Method
360° Full-time Automatic Balancing (Inclination Range: Forward & Backward 15°, Left & Right 8°, Other Directions 8~15°)
Operation Mode
Obstacle Height
Backward: 220mm
Forward:150mm
Minimum Turning Radius
Wheeled Quadruped Mode: 821mm
Caterpillar Mode: 590mm
Adapted Stair Dimension
Backrest Tilt Angle
90~135mm
Height <220mm, Inclination <40°
1. Remote Control
2. Joystick
3. APP
4. Automatic Follow
5. Wireless Key
Lifting Range
Maximum:750mm
Minimum:414mm
Uphill Angle
Backward: 40°
Forward: 15°
(Wheeled Quadruped Mode)
The above mentioned product functions and parameters are subject to the final delivery.
